The last few months has been dominated by bug-fixing and testing in Evennia-land. A lot more new users appears to be starting to use Evennia, especially from the MUSH
world where the Evennia-based Arx, After the Reckoning
is, while still in alpha, currently leading the charge.
With a new influx of users comes the application of all sorts of use- and edge-cases that stretch and exercise the framework in all the places where it matters. There is no better test of code than new users trying to use it unsupervised! Evennia is holding up well overall but there are always things that can be improved.
- I reworked the way on-object Attributes was cached (from a stupid but simple way to a lot more sophisticated but harder way) and achieved three times faster performance in certain special cases people had complained about. Other issues also came to view while diving into this, which could be fixed.
- I reworked the venerable batch command and batchcode processors (these allow to create a game world from a script file) and made their inputs make more sense to people. This was one of the older parts of Evennia and apart from the module needing a big refactoring to be easier to read, some parts were pretty fragile and prone to break. Especially when passing it file names tended to be confusing since it understood only certain relative paths to the files to read in and not even I could remember if one should include the file ending or not. This was cleaned up a lot.
- Lots of changes and updates were made to the RPSystem contrib, which optionally adds more advanced roleplaying mechanics to Evennia. The use of this in Evennia's demo game (Ainneve, being separately developed) helps a lot for ironing out any remaining wrinkles.
- Lots and lots of other fixes and smaller feature updates were done (About 150 commits and 50 Issues closed since end of summer).
A fun thing with a growing user base is that we are also starting to see a lot more Pull requests and contributions. Thanks a lot, keep 'em coming!
- Map system contrib (merged), for creating a world based on ASCII map. Talking about maps, users contributed not just one but two new tutorials for implementing both static and dynamic maps with Evennia.
- Webclient notifications (pending), for making the webclient show us in a clearer way when it gets updated in a different tab. A more advanced implementation awaits the webclient being expanded with a proper client-side option window; there is currently a feature request for this if anyone's interested in taking it on.
- AI system contrib (pending). This is a full AI backend for adding complex behaviors to game agents. It uses Behavioral trees and is designed to be modified both in code and from inside the game.
- Action system contrib (pending). This contrib assigns the actions of Characters a time cost and delays the results of commands the given time. It also allows players to go into turn-based mode to enforce a strict action order.
- Lots of now closed PRs were contributed by the Arx lead developer to fix various bugs and edge-cases as they came up in live use.
The fixing and tightening of the nuts and bolts will likely continue the remainder of the year. I'm currently working on a refactoring of the way command sets are merged together (see the end of my blog post on Evennia in pictures
for a brief summary of the command system). But with so much new blood in the community, who can tell where things will turn from here!
In the month or so since the merger of Evennia's development branch and all its web-client updates, we have been in bug-fixing mode as more people use and stress the code.
There have been some new features as well though - I thought it could be interesting to those of you not slavishly following the mailing list.
Shared web login
When you are logged into the website you will now also auto-login to your account in the web client - no need to re-enter the login information! The inverse is also true. You still need to connect to game at least once to create the account, but after that you will stay connected while the browser session lasts.
Evennia's nick(name) system is a way to create a personal alias for things in game - both to on-the-fly replacing text you input and for referring to in-game objects. In the old implementation this replacement was simply matched from the beginning of the input - if the string matched, it was replaced with the nick.
In this new implementation, the matching part can be much more elaborate. For example you can catch arguments and put those arguments into the replacement nick in another order.
Let's say we often use the @dig command this limited way:
> @dig roomname;alias = exit;alias, backexit;alias
Let's say we find this syntax unintuitive. The new nick system allows to change this by catching the arguments in your nick and put it into the "real" command. Here is an example of a syntax putting the aliases in parentheses and separating all components with commas: > nick newroom $1($2), $3($4), $5($6) = @dig $1;$2 = $3;$4, $5;$6
From here on you can now create your rooms with entries like this: > newroom The great castle(castle), to the castle(castle), back to the path(back)
I have added a new "multidescer" to the contrib folder. A multidescer is (I think) a MUSH term for a mechanism managing more than one description. You can then combine any of these various descriptions into your "active" description.
An example of usage:desc hat = a blue hat. desc basic = This is a tall man with narrow features.desc clothing = He is wearing black, flowing robes.
These commands store the description on the Character and references them as unique keywords. Next we can combine these strings together in any order to build the actual current description: > desc/set basic + |/ + clothing + On his head he has + hat > look selfThis is a tall man with narrow features. He is wearing black, flowing robes. On his head he has a blue hat.
This allows for both very flexible and easy-to-update descriptions but also a way to handle freeform equipment and clothing. And you can of course use the nick system to pre-format the output> nick setdesc $1 $2 $3 $4 = $1 + |/ + clothing + On his head he has a $4
This way you can clothe yourself in different outfits easily using the same output format:> setdesc basic clothing hat
The multidescer is a single, self-contained command that is easy to import and add to your game as needed.
... There's also plenty of bug fixes, documentation work and other minor things or course.
Anyway, summer is now upon us here in the northern hemisphere so things will calm down for a bit, at least from my end. Have a good 'un!
GriatchImage by ryancr (released under Creative Commons)
Evennia in pictures
by Griatch, September 2015
Since it is no longer available to read on OR, I'm reposting it in full here.
The MU* development system Evennia works quite differently from many traditional MU* code bases/servers and we get questions about this from time to time. This article will try to give an overview for outsiders - using pictures!
Figure 1: The parts of the Evennia library
Evennia is a game development library. What you see in Figure 1 is the part you download from us. This will not run on its own, we will soon initialize the missing “jigsaw puzzle” piece on the left. But first let’s look at what we’ve got.
Looking at Figure 1 you will notice that Evennia internally has two components, the Portal and the Server. These will run as separate processes.
The Portal tracks all connections to the outside world and understands Telnet protocols, websockets, SSH and so on. It knows nothing about the database or the game state. Data sent between the Portal and the Server is protocol-agnostic, meaning the Server sends/receives the same data regardless of how the user is connected. Hiding behind the Portal also means that the Server can be completely rebooted without anyone getting disconnected.
The Server is the main “mud driver” and handles everything related to the game world and its database. It's asynchronous and uses Twisted. In the same process of the Server is also the Evennia web server component that serves the game’s website. That the Server and webserver are accessing the database in the same process allows for a consistent game state without any concerns for caching or race condition issues.
Now, let’s get a game going. We’ll call it mygame. Original, isn’t it?
Figure 2: The full setup for mygame
After installing evennia you will have the evennia command available. Using this you create a game directory - the darker grey piece in Figure 2 that was missing previously. This is where you will create your dream game!
During initialization, Evennia will create Python module templates in mygame/ and link up all configurations to make mygame a fully functioning, if empty, game, ready to start extending. Two more commands will create your database and then start the server. From this point on, mygame is up and running and you can connect to your new game with telnet on localhost:4000 or by pointing your browser to http://localhost:8000.
Now, our new mygame world needs Characters, locations, items and more! These we commonly refer to as game entities. Let’s see how Evennia handles those.
Figure 3: The Database Abstraction of Evennia entities
Evennia is fully persistent and abstracts its database in Python using Django. The database tables are few and generic, each represented by a single Python class. As seen in Figure 3, the example ObjectDB Python class represents one database table. The properties on the class are the columns (fields) of the table. Each row is an instance of the class (one entity in the game).
Among the example columns shown is the key (name) of the ObjectDB entity as well as a Foreign key-relationship for its current “location”. From the above we can see that Trigger is in the Dungeon, carrying his trusty crossbow Old Betsy!
The db_typeclass_path is an important field. This is a python-style path and tells Evennia which subclass of ObjectDB is actually representing this entity.
Figure 4: Inheriting classes to customize entities
In Figure 4 we see the (somewhat simplified) Python class inheritance tree that you as an Evennia developer will see, along with the three instanced entities.
ObjectDB represents stuff you will actually see in-game and its child classes implement all the handlers, helper code and the hook methods that Evennia makes use of. In your mygame/ folder you just import these and overload the things you want to modify. In this way, the Crossbow is modified to do the stuff only crossbows can do and CastleRoom adds whatever it is that is special about rooms in the castle.
When creating a new entity in-game, a new row will automatically be created in the database table and then “Trigger” will appear in-game! If we, in code, search the database for Trigger, we will get an instance of the Character class back - a Python object we can work with normally.
Looking at this you may think that you will be making a lot of classes for every different object in the game. Your exact layout is up to you but Evennia also offers other ways to customize each individual object, as exemplified by Figure 5.
Figure 5: Adding persistent Attributes to a game entity.
The Attribute is another class directly tied to the database behind the scenes. Each Attribute basically has a key, a value and a ForeignKey relation to another ObjectDB. An Attribute serializes Python constructs into the database, meaning you can store basically any valid Python, like the dictionary of skills seen in Figure 5. The “strength” and “skills” Attributes will henceforth be reachable directly from the Trigger object. This (and a few other resources) allow you to create individualized entities while only needing to create classes for those that really behave fundamentally different.
Figure 6: Sessions, Players and Objects
Trigger is most likely played by a human. This human connects to the game via one or more Sessions, one for each client they connect with. Their account on mygame is represented by a PlayerDB entity. The PlayerDB holds the password and other account info but has no existence in the game world. Through the PlayerDB entity, Sessions can control (“puppet”) one or more ObjectDB entities in-game.
In Figure 6, a user is connected to the game with three Sessions simultaneously. They are logged in to their Player account Richard. Through these Sessions they are simultaneously puppeting the in-game entities Trigger and Sir Hiss. Evennia can be configured to allow or disallow a range of different gaming styles like this.
Now, for users to be able to control their game entities and actually play the game, they need to be able to send Commands.
Figure 7: Commands are Python classes too
Commands represent anything a user can input actively to the game, such as the look command, get, quit, emote and so on.
Each Command handles both argument parsing and execution. Since each Command is described with a normal Python class, it means that you can implement parsing once and then just have the rest of your commands inherit the effect. In Figure 7, the DIKUCommand parent class implements parsing of all the syntax common for all DIKU-style commands so CmdLook and others won’t have to.
Figure 8: Commands are grouped together in sets and always associated with game entities.
Commands in Evennia are always joined together in Command Sets. These are containers that can hold many Command instances. A given Command class can contribute Command instances to any number of Command Sets. These sets are always associated with game entities. In Figure 8, Trigger has received a Command Set with a bunch of useful commands that he (and by extension his controlling Player) can now use.
Figure 9: Command Sets can affect those around them
Trigger’s Command Set is only available to himself. In Figure 8 we put a Command Set with three commands on the Dungeon room. The room itself has no use for commands but we configure this set to affect those inside it instead. Note that we let these be different versions of these commands (hence the different color)! We’ll explain why below.
Figure 10: The name Command “Set” is not just a name
Command Sets can be dynamically (and temporarily) merged together in a similar fashion as Set Theory, except the merge priority can be customized. In Figure 10 we see a Union-type merger where the Commands from Dungeon of the same name temporarily override the commands from Trigger. While in the Dungeon, Trigger will be using this version of those commands. When Trigger leaves, his own Command Set will be restored unharmed.
Why would we want to do this? Consider for example that the dungeon is in darkness. We can then let the Dungeon’s version of the look command only show the contents of the room if Trigger is carrying a light source. You might also not be able to easily get things in the room without light - you might even be fumbling randomly in your inventory!
Any number of Command Sets can be merged on the fly. This allows you to implement multiple overlapping states (like combat in a darkened room while intoxicated) without needing huge if statements for every possible combination. The merger is non-destructive, so you can remove cmdsets to get back previous states as needed.
… And that’s how many illustrations I have the stamina to draw at this time. Hopefully this quick illustrated dive into Evennia helps to clarify some of the basic features of the system!
